2156 MK7

2156 MK7

17 Zone Reflow Oven


The 2156 MK7 17 reflow oven is a high volume reflow oven system with 17 heated zones and belt speeds up to 1.88m/min. The 2156 MK7 offers the lowest delta T’s, reduced nitrogen and electrical consumption and advanced flux management options. The 12” wide heater modules offer profile compatibility with competitor systems.

Technische Daten

Reflow Oven Length 869 cm (342″)
Process Gas Options Air, Nitrogen
Heated Zones Convection: 10 Top / 10 Bottom
Cool Zones 5 Top (Bottom Option)
Max Working Temperature Standard: 350°C (Option: 400°C)
Maximum PCB Width 55.9cm (22”)
Cleanroom Option Down to Class 1000


  • Built-in Thermal Monitoring
  • Nitrogen Capable to < 100 ppm
  • Energy Management System
  • Virtually No Maintenance
  • 12” Wide Heater Modules
