Beschreibung
The 1912MK5-VR contains 3 infrared heated zones and 11 convection zones, giving the flexibility to subdivide a profile into smaller segments and allowing for more refined “profile sculpting” – a must for demanding Lead Free Applications. Perfect for high volume manufacturing with 382cm (150”) in heated length, it provides low maintenance requirements and cost of ownership.
Technische Daten
| Oven Length | 590cm |
| Process Gas Options | Air, Nitrogen, Formic Acid, forming gas |
| Heated Zones | Convection: 11 Top / 11 Bottom IR: 3 Top |
| Heated Length (Convection/Total) | 290 cm / 382 cm |
| Cool Zones | 3 Top (Bottom Option) |
| Max Working Temperature (Convection / IR) | Standard: 350°C / 400°C, Option: 400°C / 480°C |
| Min Vacuum | Standard:10 Torr Option: < 10 Torr |
| Max Board Size | 350mm (L) x 350mm (W) x 29mm (H) |
| Cleanroom Option | Down to Class 1000 |
